MIL-DTL-82068D
TABLE I. Pump operating parameters.
Tank
Flow
Operating Tank drain
Engine size min
Trailer net weight 1
Size capacity capacity pressure
flow rate (brake horsepower
(max pounds (lb))
(gallons) (gpm)
(psi)
(gpm)
(bhp))
A
400
25
700
25
12 hp electric start
2,300
B
500
25
700
25
12 hp electric start
2,300
C
200
10
400
10
5 hp manual start
1,200
1
Trailer net weight includes a dry, empty fuel tank.
1.3 Part or identifying number (PIN). The PIN to be used for pesticide sprayers acquired
to this specification is created as follows:
M 82068 - X
Example: M82068-2
1 - Size A - 400-gallon tank; 25 gpm at 700 psi
2 - Size B - 500-gallon tank; 25 gpm at 700 psi
3 - Size C - 200-gallon tank; 10 gpm at 400 psi
Specification number
Denotes military specification
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this
specification. This section does not include documents cited in other sections of this specification or
recommended for additional information or as examples. While every effort has been made to ensure
the completeness of this list, document users are cautioned that they must meet all specified
requirements of the documents cited in sections 3 and 4 of this specification, whether or not they are
listed.
2.2 Government documents.
2.2.1 Standard. The following standard forms a part of this document to the extent
specified herein. Unless otherwise specified, the issue of this document is that cited in the
solicitation or contract.
DEPARTMENT OF DEFENSE STANDARD
MIL-STD-130
- Identification Marking of U.S. Military Property
(Copies of this document are available online at https://assist.daps.dla.mil/ or from the
Standardization Document Order Desk, 700 Robbins Avenue, Building 4D, Philadelphia, PA
19111-5094.)
